This automatic optical Fiber tensile testing system is designed for operator skill independent use in production and lab settings. Two basic design designs permit the consumer to select between a set up for regular linear Proof screening and with extra mandrels for rotary higher strength testing.
The linear version is made for production Proof testing with causes as much as 22 N. Motor-driven clamps with very carefully designed rubber inserts be sure that the Fiber Drawing Machine will not be damaged inside the testing procedure while concurrently getting rid of the necessity for another air provide. Levels of pulling force, pulling velocity and hold time are programmable and conveniently available to the operator through the built in Liquid crystal display touch screen control. Data from assessments can be stored and accessed using the USB dock or Ethernet interface.
Mandrels of the identical style as with NYFORS’ optical Fiber recoaters can easily be mounted on the Proof tester inside the rotary higher strength settings. The Fiber is covered round the two mandrels which support it having a unique clamping mechanism. This way greater loads can be applied on the Fiber, allowing breaking strength tests below controlled circumstances.
Changeable clamp positioning facilitates screening using the highest force levels as well as screening of short Fiber measures. The compact and light weight style makes the tool easy to move around in a lab atmosphere and to incorporate in a creation work table in which space reaches reasonably limited. The equipment is really a lightweight and light-weight tool ideal for screening the potency of visual fibers approximately 30 N. The machine is designed to meet all sorts of applications in which a strength test needs to be performed.
The device is made with the consumer in mind. The Sheathing Line is definitely put into the guided linear clamps, and the screening begins automatically having a “One Touch” go switch. The built in microprocessor controls all the essential guidelines such as tugging force, tugging speed and hold time. This enables for a totally managed check every time.
The equipment can be connected to an outside PC, which enables usage of all automated guidelines and settings. The machine is tailored to stand-alone use or to the incorporation into different subsystems. The equipment has an extensive capacity for signing and saving information including pulling force, tugging speed and Fiber diameter as well as other guidelines.
Two recoat injector configurations can be found. The PTR307 utilizes an automated water pump to inject the recoat materials. The amount of material dispensed from the automatic injector is managed by hand through the top-installed “Inject” switch or programmed in to the device making use of the tablet pc control. The PTR307B features a manual recoat shot system that requires an individual to manually dispense the recoat materials in to the mold cavity; a substitute injector for your PTR307B recoater is available listed below. Please note that the automatic injector is only compatible with higher-directory recoat materials, whilst the manual injector works with each reduced- and- directory recoat material; both of them are marketed separately below. Make sure you get in touch with Technology Support for additional information.
he handbook injector can be installed to compatible Fiber recoaters using the 4-40 anchoring screws on the recoater housing (see photo for the right). Make use of a 3/32″ hex key to secure the injector prior to use. For connecting the PTRRRM towards the recoater mold, tighten up the connector at the end of the eco-friendly plastic material tubes, then loosen by a 1/4 choose enable rotation.
The injector comes with a distribution device as well as 2-position choice handle for directing the flow of recoat material. A knurled dispensing screw with the inner plunger acts as a syringe for your recoat materials. To fill the syringe, point the handle downward (i.e., toward the recoat container), then rotate the knurled dispensing attach counterclockwise till it spins easily to fill the syringe (shown inside the picture to the right). Then, to inject the recoat materials into the mold, point the lever horizontally (i.e., facing qyjflh knurled screw) and spin the screw clockwise till nearby the end of the journey range is achieved. Avoid bottoming the dispenser since this may damage the internal plunger; also take care when re-interesting the threads in order to avoid cross threading the dispensing screw. A number of fill up/inject actions may be needed till air is displaced in the program. Use camera lens tissue plus an acetone or alcohol cleansing solution to collect SZ Stranding Line materials that runs through the mold.
